Expanders

The expander lasers from Picotronic are used when laser beams have to be expanded and thus ensure extensive illumination of the field of view. (small inteference patterns in field of view within tolerance) The expander laser modules are used, for example, for measuring tasks in research and development or they are used as brighteners in night vision technology. Despite their higher output power, the expander laser modules are still assigned to laser class 1 or 2, which is why they do not have to be registered and a laser safety officer is not required in your company. The laser module EJ658-10-3 (14x26) 50DEG-AWL is also used to generate holograms in the hobby area and is listed and recommended in the book "Holograms for DIY". Operating Voltage 3 V DC Image processing Uniform illumination Compact size Laser Class 2M Geeignet zur Anfertigung von Hologrammen im Hobby-Bereich und im Buch "Hologramme zum Selbermachen" empfohlen. Laserstrahl aufgeweitet für eine flächige Ausleuchtung (geringfügige Interferenzringe im Strahlprofil innerhalb der Toleranz normal) Öffnungswinkel 50° Punktgröße ca. 400mm bei einem Abstand von 0,3m Laserklasse 2 Accessesories Magnetic Mount for Lasermodul 14mm14mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Magnetic Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm Bracket for Lasermodule 14mmØ14mm(25x72) Halterung-Ballhead für Lasermodule mit Durchmesser 14mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132000844 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 10 mW Laser Class: 2M Fan Angle: 50 ° Size of Laserdot: <400mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 50 - 150, typ 100 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø14x45 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 5 mm Weight: 9 g

isolated Expander lasermodule, red, 658nm, 100mW, 3V DC, 14x26mm, class 3R Operating Voltage 3 V DC Image processing Uniform illumination Compact size Laser Class 3R Accessesories Magnetic Mount for Lasermodul 14mm14mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Magnetic Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm Bracket for Lasermodule 14mmØ14mm(25x72) Halterung-Ballhead für Lasermodule mit Durchmesser 14mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129044309 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 50 ° Size of Laserdot: <400mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 90 - 270, typ 180 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø14x26 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 5 mm Weight: 19 g

isolated expander laser, red, 658nm, 100mW, 5V DC, 9,5x23mm, class 3R Image processing Uniform illumination Modulated Protection lens Compact size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132010638 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 17 ° Size of Laserdot: <90mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: diode Protection Lens: yes Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Operating Voltage: 4.5 - 5.5, typ 5 V DC Operating Current: 180 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø9.5x23 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 5.5 mm Weight: 18 g

focusable isolated Expander lasermodule, green, 532nm, 1mW, 3V DC, 24x120mm, class 2, with DC 2.5mm plug Operating Voltage 3 V DC Glas lenses anti reflex coated Laser Class 2 Adjustable focus Uniform illumination Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4260129042855 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 1 mW Laser Class: 2 Operating Distance: 200 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: YVO4+KTP Stability: +/- 20% @ 15-30°C Focus: adjustable Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 150 - 450, typ 300 mA Connector: 2.5 mm DC plug (GND pole inner) Mechanical Parameters Size: Ø24x120 mm Material: aluminium Cable length: 300 mm Wire type: 22AWG, black, 3,6mm Output Aperture: 20 mm Weight: 87 g Buy E532-1-3(24x120)APT20-C300-C on Amazon

isolated expander laser, infrared, 830nm, 110mW, 3V DC, 9,5x28mm, class 3R Image processing Uniform illumination Modulated Spreading lens Compact size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4055132012465 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 110 mW Laser Class: 3R Fan Angle: 50 ° Size of Laserdot: <400mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Protection Lens: no Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Operating Voltage: 3 - 3, typ 3 V DC Operating Current: 140 - 180, typ 160 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø9.5x28 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 4.2 mm Housing Color: black Weight: 18 g Stripping of wire: 5 mm

Dot lasermodule, red, 650nm, 2mW, 3V DC, 16x60mm, class 1 Accessesories Magnetic Mount for Lasermodul 16mm16mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 16mm Bracket for Lasermodule 16mmØ16mm(25x75) Halterung-Ballhead für Lasermodule mit Durchmesser 16mm Picotronic Bracket Mount-16(30x65)Ø16mm(30x65) MOUNT für Lasermodule mit Durchmesser 16mm Magnetic Mount for Lasermodul 16mmØ16mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 16mm Mount for Lasermodul 16mmØ16mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 16mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132001094 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 2 mW Laser Class: 1 Operating Distance: 10 m Optics: glass lens AR coated Laser technology: diode Electrical Parameters Operating Voltage: 3 V DC Operating Current: 50 mA Mechanical Parameters Size: Ø16x60 mm Material: aluminium Cable length: 100 mm Output Aperture: 8 mm Weight: 43 g Buy E650-2-3(16x60)APT8 on Amazon

isolated Expander lasermodule, green, 532nm, 5mW, 3V DC, 43x200mm, class 1M Operating Voltage 3 V DC Laser Class 1M Image processing Glas lenses anti reflex coated Fixed focus Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4260129045986 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 5 mW Laser Class: 1M Beam Diameter: 30 mm Operating Distance: 100 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: YVO4+KTP Stability: +/- 20% @ 15-30°C Focus: fixed Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 75 - 225, typ 150 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø43x200 mm Material: aluminium Cable length: 100 mm Output Aperture: 30 mm Weight: 200 g Buy E532-5-3(43x200)APT30 on Amazon

Picotronic Green Laser Designator 8mW, expander lasermodule, direct green Laserdiode, 520nm, 6V DC, 2xCR123A, Laser Class 2M, focusable, battery operated Eye safe Large operating range High visibility Battery operated Adjustable spot size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4055132000325 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 6,000 h Operating Temperature: -10°C - 60 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 8 mW Laser Class: 2M Divergence: I - 1.5 mrad Size of Laserdot: <35mm@10m Operating Distance: 1,000 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: Single Mode Diode Stability: +/- 3% @ -10-50°C Focus: adjustable Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 5.5 - 6.3, typ 6 V DC Operating Current: 75 - 125, typ 100 mA Battery: CR123A Lithium Battery, 3V 1400mAh Battery count: 2 Mechanical Parameters Size: Ø35x182 mm Material: aluminium Output Aperture: 25 mm Housing Color: black Weight: 174 g Protection Class: IP 54

modulated isolated expander laser, red, 658nm, 100mW, 5V DC, 9,5x23mm, class 3R, no optics Image processing Uniform illumination Modulated Protection lens Compact size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132009021 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 17 ° Size of Laserdot: 50x80mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Protection Lens: no Focus: (300mm) Electrical Parameters Potential of Housing: isolated Max. Mod. Frequency: 200 kHz Operating Voltage: 4.5 - 5.5, typ 5 V DC Operating Current: 180 mA Cable color positive: red Cable color GND: black Cable color modulation: yellow Mechanical Parameters Size: Ø9.5x20 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Weight: 18 g

Dot lasermodule, infrared, 850nm, 0.85mW, 5V DC, 8x25mm, class 1,m VCSEL Laserdiode, spot size @2m: min 7.5mm, typ 9.5mm, max 11.5mm@2m Laser Class 1 Operating Voltage 5 V DC Spotsize @ 2m: min 7.5mm Typ 9.5mm Max 11.5mm@2m Accessesories Magnetic Mount for Lasermodul 8mmØ8mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 8mm Magnetic Mount for Lasermodul 12mmØ8mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 8mm Mount for Lasermodul 08mmØ8mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 8mm Bracket for Lasermodule 8mmØ8mm(25x66) Halterung-Ballhead für Lasermodule mit Durchmesser 8mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Bracket for Lasermodule 8mmØ8mm(58x145) LF-Halterung für Lasermodule mit Durchmesser 8mm Main Data Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 60 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 0.85 mW Laser Class: 1 Divergence: J - 2.0 mrad Size of Laserdot: min 7.5mm, typ 9.5mm, max 11.5mm@2m Operating Distance: 2 m Optics: glass lens AR coated Laser technology: VCSEL Diode Focus: fixed (2000mm) Electrical Parameters Potential of Housing: isolated Max. Mod. Frequency: 0.1 kHz Operating Voltage: 4.5 - 5, typ 5 V DC Operating Current: 5 - 25, typ 15 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø8x25 mm Material: aluminium Cable length: 300 mm Wire type: 28AWG, Typ 1061, UL1061 Output Aperture: 2.4 mm Housing Color: brass Weight: 5 g Stripping of wire: 10 mm

Dot lasermodule, infrared, 850nm, 0.85mW, 5V DC, 8x26mm, class 1,m VCSEL Laserdiode Laser Class 1 Operating Voltage 5 V DC Glas lenses anti reflex coated Compact size Accessesories Magnetic Mount for Lasermodul 8mmØ8mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 8mm Magnetic Mount for Lasermodul 12mmØ8mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 8mm Mount for Lasermodul 08mmØ8mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 8mm Bracket for Lasermodule 8mmØ8mm(25x66) Halterung-Ballhead für Lasermodule mit Durchmesser 8mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Bracket for Lasermodule 8mmØ8mm(58x145) LF-Halterung für Lasermodule mit Durchmesser 8mm Main Data Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: 10°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 0.85 mW Laser Class: 1 Divergence: J - 2.0 mrad Fan Angle: 0.38 ° Size of Laserdot: 40mm@6m Operating Distance: 6 m Optics: glass lens AR coated Laser technology: VCSEL Diode Focus: fixed (6.0m) Electrical Parameters Potential of Housing: isolated Operating Voltage: 4.5 - 5, typ 5 V DC Operating Current: 5 - 15, typ 10 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø8x26 mm Material: aluminium Cable length: 340 mm Wire type: 22AWG, PTFE Output Aperture: 2.5 mm Housing Color: black Weight: 5 g Stripping of wire: 10 mm

Dot lasermodule, infrared, 850nm, 0.8mW, 5V DC, 8x26mm, class 1,m VCSEL Laserdiode, spot size @2m: min 10mm, typ. 11.5mm, max 13mm Laser Class 1 Operating Voltage 5 V DC Spotsize @ 2m: min 10mm Typ. 11.5mm Max 13mm Accessesories Magnetic Mount for Lasermodul 8mmØ8mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 8mm Magnetic Mount for Lasermodul 12mmØ8mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 8mm Mount for Lasermodul 08mmØ8mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 8mm Bracket for Lasermodule 8mmØ8mm(25x66) Halterung-Ballhead für Lasermodule mit Durchmesser 8mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Bracket for Lasermodule 8mmØ8mm(58x145) LF-Halterung für Lasermodule mit Durchmesser 8mm Main Data EAN: 4055132017682 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 60 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 0.8 mW Laser Class: 1 Divergence: J - 2.0 mrad Size of Laserdot: min 10mm, typ 11.5mm, max 13mm@2m Operating Distance: 2 m Optics: glass lens AR coated Laser technology: VCSEL Diode Focus: fixed (2000mm) Electrical Parameters Max. Mod. Frequency: 0.1 kHz Operating Voltage: 4.5 - 5, typ 5 V DC Operating Current: 5 - 25, typ 15 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø8x26 mm Material: Brass Cable length: 300 mm Wire type: 28AWG, Typ 1061, UL1061 Output Aperture: 2.4 mm Housing Color: brass Weight: 5 g Stripping of wire: 10 mm

focusable isolated Expander lasermodule, green, 532nm, 5mW, 5V DC, 24x120mm, class 2M Operating Voltage 5 V DC Glas lenses anti reflex coated Laser Class 2M Adjustable focus Uniform illumination Accessesories 5V Power supply 5V DC (1000mA)Netzteil, Ausgang: 5V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4260129044286 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 5 mW Laser Class: 2M Operating Distance: 150 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: Solid State (YVO4+KTP) Stability: +/- 20% @ 15-30°C Focus: adjustable Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 4.7 - 5.3, typ 5 V DC Operating Current: 80 - 180, typ 100 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max. Mechanical Parameters Size: Ø24x120 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 20 mm Housing Color: black Weight: 120 g Stripping of wire: 5 mm Buy E532-5-5(24x120)APT20 on Amazon

isolated expander laser, red, 658nm, 100mW, 3V DC, 9,5x28mm, class 3R, sharp diode Image processing Uniform illumination Modulated Spreading lens Compact size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132012434 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 50 ° Size of Laserdot: <400mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Protection Lens: yes Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Operating Voltage: 3 - 3, typ 3 V DC Operating Current: 150 - 250, typ 200 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø9.5x28 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 4.2 mm Housing Color: black Weight: 4.5 g

modulated focusable Expander lasermodule, red, for Illumination and Inspection, 658nm, 100mW, 5V DC, 22x70mm, class 3R Operating Voltage 5 V DC Laser Class 3R Image processing Adjustable focus High Power Accessesories Picotronic Bracket PENDULUM-MOUNT-22 Magnetic Mount for Lasermodul 22mm22mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 22mm Picotronic Bracket MOUNT-BASE-PLATE-01Grundplatte mit Montagedorn Ø22mm zur Wand- und Deckenbefestigung Befestigung rotierbar. Die Halterung ist für eine befestigung auf einer Ø22mm Montagewelle vorgesehen. Die Gesamthöhe der Halterung b… Magnetic Mount for Lasermodul 22mmØ22mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 22mm Mount for Lasermodul 22mmØ22mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 22mm Bracket for Lasermodule 22mmØ22mm(25x80) Halterung-Ballhead für Lasermodule mit Durchmesser 22mm 5V Power supply 5V DC (1000mA)Netzteil, Ausgang: 5V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic Bracket PENDULUM-MOUNT-360Shots Picotronic Bracket PENDULUM-MOUNT-22-WIRE Main Data EAN: 4055132008925 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 17 ° Size of Laserdot: <2600mm@100m Operating Distance: 10 m Optics: glass lens AR coated Laser technology: Single Mode Diode Focus: adjustable Electrical Parameters Potential of Housing: isolated Max. Mod. Frequency: 100 kHz Operating Voltage: 4.5 - 5, typ 5 V DC Operating Current: 80 - 240, typ 160 mA Cable color positive: red Cable color GND: blue Cable color modulation: yellow Power Supply: Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max. Mechanical Parameters Size: Ø22x70 mm Material: aluminium Cable length: 100 mm Output Aperture: 17.5 mm Housing Color: black Weight: 30 g

remaining stock Image processing Uniform illumination Modulated Protection lens Compact size Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129046181 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 17 ° Size of Laserdot: <90mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: diode Protection Lens: yes Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Max. Mod. Frequency: 500 kHz Operating Voltage: 4.5 - 5.5, typ 5 V DC Operating Current: 180 mA Cable color positive: red Cable color GND: black Cable color modulation: yellow Mechanical Parameters Size: Ø9.5x23 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 5.5 mm Weight: 18 g

Focusable isolated Expander lasermodule, green, 532nm, 10mW, 3V DC, 24x120mm, class 3R Operating Voltage 3 V DC Glas lenses anti reflex coated Laser Class 3R Adjustable focus Uniform illumination Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4055132000462 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 10 mW Laser Class: 3R Operating Distance: 300 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: Solid State (YVO4+KTP) Stability: +/- 20% @ 15-30°C Focus: adjustable Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 50 - 350, typ 150 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø24x120 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 20 mm Housing Color: black Weight: 120 g Stripping of wire: 5 mm

isolated Expander lasermodule, red, 650nm, 12mW, 3V DC, 43x175mm, class 3R Laser Class 3R Operating Voltage 3 V DC Image processing Glas lenses anti reflex coated Compact size Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132010331 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 12 mW Laser Class: 3R Beam Diameter: 30 mm Operating Distance: 150 m Optics: glass lens AR coated Laser technology: diode Focus: fixed Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 50 - 150, typ 100 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø43x175 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 30 mm Weight: 151 g

focusable isolated Expander lasermodule, red, 635nm, 2mW, 3V DC, 24x96mm, class 3R Operating Voltage 3 V DC Image processing Laser Class 3R Glas lenses anti reflex coated Adjustable focus Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132010898 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 2 mW Laser Class: 3R Operating Distance: 20 m Optics: glass lens AR coated Laser technology: Single Mode Diode Focus: adjustable Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 20 - 55, typ 35 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø24x96 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 20 mm Housing Color: black Weight: 75 g

focusable isolated Expander lasermodule, red, 635nm, 1mW, 3V DC, 24x96mm, class 2 Operating Voltage 3 V DC Image processing Laser Class 2 Glas lenses anti reflex coated Adjustable focus Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132008352 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 1 mW Laser Class: 2 Operating Distance: 10 m Optics: glass lens AR coated Laser technology: Single Mode Diode Opt. Power Stability at const. Temp.: < 1 % Focus: adjustable Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 20 - 55, typ 35 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø24x96 mm Material: aluminium Cable length: 200 mm Wire type: Belden, Typ 1007, 26AWG Output Aperture: 20 mm Housing Color: black Weight: 75 g Stripping of wire: 5 mm Buy E635-1-3(24x96)APT20 on Amazon

Isolated Expander lasermodule, red, 650nm, 2mW, 3V DC, 43x175mm, class 1M Operating Voltage 3 V DC Laser Class 1M Image processing Uniform illumination Fixed focus Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132000585 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 2 mW Laser Class: 1M Divergence: E - 0.6 mrad Beam Diameter: 30 mm Size of Laserdot: <30mm@5m Operating Distance: 30 m Optics: glass lens AR coated Laser technology: Single Mode Diode Focus: fixed (5.0m) Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 15 - 55, typ 42 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø43x175 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 30 mm Housing Color: black Weight: 190 g Stripping of wire: 5 mm Buy E650-2-3(43x175)APT30 on Amazon

modulated isolated expander laser, red, 658nm, 100mW, 5V DC, 14x45mm, class 3R, FIRST GENERATION, shielded wire Image processing Uniform illumination Modulated Protection lens Compact size Accessesories Magnetic Mount for Lasermodul 14mm14mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Magnetic Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm Mount for Lasermodul 14mmØ14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm Bracket for Lasermodule 14mmØ14mm(25x72) Halterung-Ballhead für Lasermodule mit Durchmesser 14mm 5V Power supply 5V DC (1000mA)Netzteil, Ausgang: 5V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132018375 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 10,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 100 mW Laser Class: 3R Fan Angle: 50 ° Size of Laserdot: <400mm@0.3m Operating Distance: 1 m Optics: glass lens AR coated Laser technology: Single Mode Diode Protection Lens: yes Focus: fixed (300mm) Electrical Parameters Potential of Housing: isolated Max. Mod. Frequency: 200 kHz Operating Voltage: 4.5 - 5.5, typ 5 V DC Operating Current: 90 - 180, typ 135 mA Cable color positive: white Cable color GND: black Cable color modulation: yellow Power Supply: Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max. Stripping of cable cover: 50 mm Mechanical Parameters Size: Ø14x45 mm Material: aluminium Cable length: 450 mm Wire type: RVVP 3x0.2, Shielded Wire Output Aperture: 5 mm Housing Color: black Weight: 18 g Stripping of wire: 5 mm

focusable isolated Expander lasermodule, green, 532nm, 1mW, 3V DC, 24x120mm, class 2, with DC 2.5mm plug Operating Voltage 3 V DC Glas lenses anti reflex coated Laser Class 2 Adjustable focus Uniform illumination Accessesories Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4055132016074 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 0.6 mW Laser Class: 2 Operating Distance: 200 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: YVO4+KTP Stability: +/- 20% @ 15-30°C Focus: adjustable Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 150 - 450, typ 300 mA Connector: 2.5 mm DC plug (GND pole inner) Mechanical Parameters Size: Ø24x120 mm Material: aluminium Cable length: 300 mm Wire type: 22AWG, black, 3,6mm Output Aperture: 20 mm Weight: 87 g

focusable isolated Expander lasermodule, green, 532nm, 5mW, 3V DC, 24x120mm, class 2M Operating Voltage 3 V DC Glas lenses anti reflex coated Laser Class 2M Adjustable focus Uniform illumination Accessesories Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications Main Data EAN: 4260129046846 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: 15°C - 30 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: expander Optical Power: 5 mW Laser Class: 2M Operating Distance: 150 m Optics: glass lens AR coated Beam Mode: TEM00 Laser technology: Solid State (YVO4+KTP) Stability: +/- 20% @ 15-30°C Focus: adjustable Warm up time: < 15 min Electrical Parameters Potential of Housing: isolated Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 150 - 400, typ 300 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø24x120 mm Material: aluminium Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 20 mm Housing Color: black Weight: 120.5 g Buy E532-5-3(24x120)APT20 on Amazon
