Mount for Lasermodul 14mm

€72.90*

Prices incl. VAT. No shipping costs for orders over 100 Euro in the EU

Available in 13 days, delivery time 1-2 days

Notify me when the item is available.

Privacy

By selecting continue you confirm that you have read our data protection information and accepted our general terms and conditions. *

Product number: 70114096

Product information "Mount for Lasermodul 14mm"

Ø14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm

Solid, very robust laser aluminum mount for industrial applications. Industrial quality. Bracket is adjustable in all degrees of freedom. Baseplate with two different mounting options:

Hole for mounting on e.g. walls and ceilings.
Existing M5 female thread can be used for installation on machines, etc.

Anodized aluminium
Very robust
For industrial applications

Halterung für Lasermodule mit Durchmesser 14mm.
Befestigung: Drei Innengewinde im Standfuß M5x0.8; Vier Durchgangslöcher im Standfuß Ø4,2mm
Das Lasermodul wird mit einer Klemmschraube in der Halterung fixiert. Der farbige Standfuß wird mit Hilfe von drei Inbusschrauben mit dem Mount verbunden.
Material: Aluminium; Farbe: Schwarz
Hochwertige Halterung für industrielle Anwendungen.

Main Data

EAN: 4260129042305
customs tarif number: 90139080000

Technical Parameters

Operating Temperature: -20°C - 50 °C
Storage Temperature: -50°C - 70 °C

Electrical Parameters

Operating Voltage: max 0 V DC

Mechanical Parameters

Size: Ø45x75 mm
Material: aluminium
Housing Color: black
Weight: 141 g

Mount Parameters

Total Height (h1): 75 mm
Height to Laseraxis (h2): 60 mm
Height of Base (h3): 25 mm
Mount Diameter (d1): Ø 14 mm
Diameter of Base (d2): Ø 45 mm
Width of Mount (b): 26 mm
Height of Mount (g): 50 mm
Height of Mount Head (k): 50 mm
Depth of Mount (t): 15 mm
Angle of Rotation Alpha (α): 360 °
Angle of Rotation Beta (β): ± 90 °
