Dot laser, red, 650 nm, 1 mW, 3 V DC, Ø7x14 mm, Laser Class 2, Focus adjustable, Cable length 50 mm
€22.90
Available, delivery time: 1-2 days
Product information "Dot laser, red, 650 nm, 1 mW, 3 V DC, Ø7x14 mm, Laser Class 2, Focus adjustable, Cable length 50 mm"
focusable Dot lasermodule, red, 650nm, 1mW, 3V DC, 7x14mm, class 2
- Operating Voltage 3 V DC
- Laser Class 2
- Compact size
- Adjustable focus
- Low cost
- The article is DG650-1-3(7x14)-ADJ-C50
Main Data
- EAN: 4055132007690
- Warranty: 1 years
- Customs tariff number: 90132000000
Technical Parameters
- Lifetime: > 5,000 h
- Operating Temperature: -20°C - 50 °C
- Storage Temperature: -40°C - 80 °C
Optical Parameters
- Beam Shape: Dot
- Optical Power: 1 mW
- Laser Class: 2
- Divergence: G - 0.8 mrad
- Size of Laserdot: adjustable
- Operating Distance: 10 m
- Optics: acryl lense
- Laser technology: diode
- Focus: adjustable
Electrical Parameters
- Potential of Housing: VDD(+)
- Operating Voltage: 2.7 - 3.3, typ 3 V DC
- Operating Current: 15 - 40, typ 25 mA
- Cable color positive: red
- Cable color ground: blue
- Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.
Mechanical Parameters
- Size: Ø7x14 mm
- Material: Brass
- Cable length: 50 mm
- Output Aperture: 2.5 mm
- Weight: 1.5 g
Holosun
- BKA exception: no
Accessesories
Power supply 3V DC (1200mA)
Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC
certified laser safety glasses PICO-LPG-635-660 according to DIN EN 207, suitable wavelength range red >630 - 700 nm, comfortable fit over glasses or alone, side protection for wide field of view, for laser welding, laser cutting, laser marking, for cosmetic applications, research and development
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
