Linienlaser Strichlaser rot 650nm 16mW 90° 24VDC Aluminiumgehäuse 20x80mm
€259.90*
Available, delivery time: 1-2 days
Product information "Linienlaser Strichlaser rot 650nm 16mW 90° 24VDC Aluminiumgehäuse 20x80mm"
Linienlaser rot 650nm 16mW 90° 24VDC
- Operating Voltage 24V DC
- Isolated housing
- Laser Class 1
- Small laser head
- Protection lens
Accessesories
Magnetic Mount for Lasermodul 20mm
20mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 20mm
Picotronic BRACKET-20-AL
Ø20mm(35x80) BRACKET für Lasermodule mit Durchmesser 20mm auf 22mm Montagewelle
Magnetic Mount for Lasermodul 20mm
Ø20mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 20mm
Magnetic Mount for 20mm Laser Module
Ø20mm (36x62) magnetic holder for laser module 20mm, diameter 36mm, height 62mm, plastic
Mount for Lasermodul 20mm
Ø20mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 20mm
Bracket for Lasermodule 20mm
ø 20mm (25x78) Halterung-Ballhead für Lasermodule mit Durchmesser 20mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development
Main Data
- EAN: 4260129048550
- Warranty: 1 years
- Customs tariff number: 90132000000
Technical Parameters
- Lifetime: > 10,000 h
- Operating Temperature: -20°C - 50 °C
- Storage Temperature: -40°C - 80 °C
Optical Parameters
- Beam Shape: Line
- Optical Power: 16 mW
- Laser Class: 2
- Divergence: H - 1.0 mrad
- Fan Angle: 90 °
- Line Thickness: <2mm@1.5m
- Operating Distance: 1.5 m
- Optics: glass lens AR coated
- Laser technology: Single Mode Diode
- Protection Lens: yes
- Focus: fixed (1500mm)
Electrical Parameters
- Potential of Housing: isolated
- Operating Voltage: 20 - 26, typ 24 V DC
- Operating Current: 5 - 25, typ 12 mA
- Connector: 2.1 mm DC socket (+pole inner)
- Cable color positive: white
- Cable color GND: black
- Stripping of cable cover: 50 mm
Mechanical Parameters
- Size: Ø20x80 mm
- Material: aluminium
- Cable length: 500 mm
- Wire type: 22AWG, black, 3,6mm
- Output Aperture: 5.5 mm
- Housing Color: black
- Weight: 63 g
- Stripping of wire: 5 mm
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Buy LH650-16-24(20x80)-C500-NT on Amazon
| Opening angle: | 90 ° |
|---|
