Doe laser, red, 635 nm, 5 mW, 5 V DC, Ø10x24 mm, Laser Class 1M, Focus adjustable, Cable length 100…

Ø10mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 10mm Solid, very robust laser aluminum mount for industrial applications Industrial quality Bracket is adjustable in all degrees of freedom Baseplate with two different mounting options: 1st: Hole for mounting on e.g. walls / ceilings 2nd: Existing M5 female thread can be used for installation on machines, etc. Anodized aluminium Very robust For industrial applications Halterung für Lasermodule mit Durchmesser 10mm. Befestigung: Drei Innengewinde im Standfuß M5x0.8; Vier Durchgangslöcher im Standfuß Ø4,2mm Das Lasermodul wird mit einer Klemmschraube in der Halterung fixiert. Der farbige Standfuß wird mit Hilfe von drei Inbusschrauben mit dem Mount verbunden. Material: Aluminium; Farbe: Schwarz Hochwertige Halterung für industrielle Anwendungen. Main Data EAN: 4260129042268 customs tarif number: 90139080000 Technical Parameters Operating Temperature: -20°C - 50 °C Storage Temperature: -50°C - 70 °C Electrical Parameters Operating Voltage: max 0 V DC Mechanical Parameters Size: Ø45x75 mm Material: aluminium Housing Color: black Weight: 141 g Mount Parameters Total Height (h1): 75 mm Height to Laseraxis (h2): 60 mm Height of Base (h3): 25 mm Mount Diameter (d1): Ø 10 mm Diameter of Base (d2): Ø 45 mm Width of Mount (b): 26 mm Height of Mount (g): 50 mm Height of Mount Head (k): 50 mm Depth of Mount (t): 15 mm Angle of Rotation Alpha (α): 360 ° Angle of Rotation Beta (β): ± 90 ° Buy MULTI-MOUNT-10(45x75) on Amazon

focusable DOE lasermodule, red, 650nm, 10mW, 3-6V DC, 10x24mm, class 2M, with DOE384, DOE 51978-Dot Truely Random Pattern 78.3° @ 640nm PC 8x1.2mm DOE optimized Laserclass depends on DOE Compact size Wide operating voltage Low cost Accessesories MULTI-MOUNT-10(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm MULTI-MOUNT-10(45x75)Mount for Lasermodul 10mm PICO-LPG-635-660certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132017958 Warranty: 1 years customs tarif number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 10 mW Laser Class: 2M Divergence: H - 1.0 mrad Size of Laserdot: adjustable Operating Distance: 10 m Optics: acryl lense Laser technology: Single Mode Diode Focus: adjustable Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 3 - 6, typ 6 V DC Operating Current: 15 - 50, typ 30 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø10x24 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Housing Color: brass Weight: 8.5 g Stripping of wire: 5 mm
