Line laser, green, 520 nm, 45 °, 5 mW, 24 V DC, Ø14x55 mm, Laser Class 1, Focus adjustable, Cable l…
€289.43
Available in 75 days, delivery time 1-2 days
Product information "Line laser, green, 520 nm, 45 °, 5 mW, 24 V DC, Ø14x55 mm, Laser Class 1, Focus adjustable, Cable l…"
The type is a laser that projects a laser line. The laser module emits light of the wavelength . This laser has a very compact design ( x ). The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. Using a special optics the laser module produces a sharp line without using rotating polygon mirrors or motors. The diode has a power of . Therefore, the module can be used in different applications and also in room light. The module is tested in Germany and it is issued with the DIN EN 60825-1:2001-11 certificate. This module is laser class .
- Laser Class 1
- Image processing
- Adjustable focus
- Compact size
- Operating Voltage 24 V DC
Accessesories
Magnetic Mount for Lasermodul 14mm
14mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm
Magnetic Mount for Lasermodul 14mm
Ø14mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm
Mount for Lasermodul 14mm
Ø14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm
Bracket for Lasermodule 14mm
Ø14mm(25x72) Halterung-Ballhead für Lasermodule mit Durchmesser 14mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development
Main Data
- EAN: 4055132020927
- Warranty: 1 years
- Customs tariff number: 90132000000
Technical Parameters
- Lifetime: > 5,000 h
- Operating Temperature: -20°C - 50 °C
- Storage Temperature: -40°C - 80 °C
Optical Parameters
- Beam Shape: Line
- Optical Power: 5 mW
- Laser Class: 1
- Divergence: C - 0.4 mrad
- Fan Angle: 45 °
- Line Thickness: adjustable
- Operating Distance: 3 m
- Optics: glass lens AR coated
- Laser technology: Single Mode Diode
- Focus: adjustable
Electrical Parameters
- Potential of Housing: isolated
- Operating Voltage: 21.6 - 26.4, typ 24 V DC
- Operating Current: 4 - 25, typ 15 mA
- Cable color positive: red
- Cable color ground: black
Mechanical Parameters
- Size: Ø14x55 mm
- Material: aluminium
- Cable length: 500 mm
- Wire type: 26AWG, 0,14mm²
- Output Aperture: 3.5 mm
- Housing Color: black
- Weight: 18 g
- Stripping of wire: 5 mm
