Certified laser safety glasses PICO-LPG-405-532 according to DIN EN 207, suitable wavelength range…

When working with laser systems of class 3R and higher, severe damage to the human eye can occur. The human eye can be permanently damaged by direct or indirect laser radiation. Injuries to the retina mostly occur in the range of 400-1400nm, while defects on the cornea or lens occur in the UV range (190-400nm). Therefore, it is essential to protect the eyes accordingly with the help of suitable laser safety glasses. The laser safety glasses certified according to the valid standard DIN EN 207 (full protection) comply with legal regulations and safely protect the eyes from dangerous laser radiation. Laser safety glasses and the filters they contain are designed to absorb the specific energy of the laser. Therefore, the optimal protective goggles must be explicitly selected for the required wavelength range, the radiation peak value, and the required optical density. Of course, daylight transmission, the field of view, and the wearing comfort of the frame also play a decisive role. The frame of the laser safety glasses prevents the lateral penetration of laser beams.

Wavelength: 180-315nm, Protection levels D LB7 + IR LB4
Wavelength: >315-532nm, Protection level DIRM LB6
Particularly suitable for: Laser BLUE 405nm, BLUE 445nm, BLUE 450, GREEN 520nm and GREEN 532nm

Suitable for laser welding, laser cutting, laser marking, research and development, or even for cosmetic applications (Please note the wavelength range!)

• Full protection
• Comfortable fit over glasses or alone
• Adjustable temple arms and side protection for a wide field of view
• CE-certified DIN EN 207
• With Picotronic logo print.

• Full protection
• Universal, comfortable fit over glasses or alone, adjustable temples, side protection for a wide field of vision
• CE-certified
• Wavelength: 180-315nm, Protection levels D LB7 + IR LB4 Wavelength: >315-532nm, Protection level DIRM LB6
• Particularly suitable for: Laser BLUE 405nm, BLUE 445nm, BLUE 450, GREEN 520nm, and GREEN 532nm.

Delivery Content

• Glasses cleaning cloth
• Glasses cord
• Flexible glasses case
• Instructions

Main Data

• EAN: 4055132003357
• Customs tariff number: 90049010000

Technical Parameters

• Operating Temperature: -50°C - 85 °C
• Storage Temperature: -50°C - 80 °C

Optical Parameters

• LB Rating: 180-315 D LB7 + IR LB4, >315-532 DIRM LB6
• Lens Color: Orange

Mechanical Parameters

• Size: 145x144x50 mm
• Material: Polymer
• Housing Color: black
• Weight: 10 g

Shop+Web

• Delivery Content: - Glasses cleaning cloth

• Glasses cord
• Flexible glasses case
• Instructions
