Dot laser, red, 650 nm, 1 mW, 24 V DC, Ø12x60 mm, Laser Class 2, Focus fixed (3.4m), Cable length 500 mm, CON-M8-3POL

Red dot laser, 650nm, 1mW, Laser Class 2, Focus 3.4m, 24V DC, 12x60mm, M8 connector

The type DBI650-1-24-FA(12X60)-F3400-M8 is a laser for projecting a red laser dot. The laser module emits radiation with a wavelength of 650nm. The laser features a compact design (12x60mm). The module is equipped with a fixed optics. The product can be excellently used in light barriers, leveling devices, or pointer applications, in industry, craft, hobby, or show areas. This module falls into laser class 2.

• With M8 connector 42-00009 (3-pin)

• Radiation pattern: elliptical point, spot size <1.25mm@3.4m
• Optical Output: 1mW (Laser Class 1); Focus 3.4m
• Compact design: 12x60mm; Shaft deviation: up to 3.0°; M8 connector (42-00009)
• For applications in, for example, light barriers, leveling devices, or pointer applications, in industry, trade, hobby, or the show sector.
• Power supply 24V.

Main Data

• EAN: 4055132039172
• Warranty: 1 years
• Customs tariff number: 90132000000

Technical Parameters

• Lifetime: > 5,000 h
• Operating Temperature: -20°C - 50 °C
• Storage Temperature: -40°C - 80 °C

Optical Parameters

• Beam Shape: Dot
• Optical Power: 1 mW
• Laser Class: 2
• Divergence: B - 0.3 mrad
• Size of Laserdot: <1.25mm@3.4m
• Operating Distance: 3.4 m
• Optics: glass lens AR coated
• Laser technology: Single Mode Diode
• Focus: fixed (3.4m)

Electrical Parameters

• Potential of Housing: isolated
• Operating Voltage: 23.5 - 25.5, typ 24 V DC
• Operating Current: 1 - 15, typ 5 mA
• Connector: CON-M8-3POL
• Cable color positive: red
• Cable color ground: black

Mechanical Parameters

• Size: Ø12x60 mm
• Material: aluminium
• Cable length: 500 mm
• Wire type: 22AWG, black, 3,6mm
• Output Aperture: 5 mm
• Housing Color: black
• Weight: 10.5 g
• Connector Pin VDD: 1
• Connector Pin GND: 3
