Mount for Lasermodul 12mm

€72.90*

Prices incl. VAT. No shipping costs for orders over 100 Euro in the EU

Available, delivery time: 1-2 days

Product number: 70112498

Product information "Mount for Lasermodul 12mm"

Ø12mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 12mm

Solid, very robust laser aluminum mount for industrial applicationsIndustrial qualityBracket is adjustable in all degrees of freedomBaseplate with two different mounting options:1st: Hole for mounting on e.g. walls / ceilings2nd: Existing M5 female thread can be used for installation on machines, etc.

Anodized aluminium
Very robust
For industrial applications

Halterung für Lasermodule mit Durchmesser 12mm.
Befestigung: Drei Innengewinde im Standfuß M5x0.8; Vier Durchgangslöcher im Standfuß Ø4,2mm
Das Lasermodul wird mit einer Klemmschraube in der Halterung fixiert. Der farbige Standfuß wird mit Hilfe von drei Inbusschrauben mit dem Mount verbunden.
Material: Aluminium; Farbe: Schwarz
Hochwertige Halterung für industrielle Anwendungen.

Main Data

EAN: 4260129042398
customs tarif number: 90139080000

Technical Parameters

Operating Temperature: -20°C - 50 °C
Storage Temperature: -50°C - 70 °C

Electrical Parameters

Operating Voltage: max 0 V DC

Mechanical Parameters

Size: Ø45x75 mm
Material: aluminium
Housing Color: black
Weight: 141 g

Mount Parameters

Total Height (h1): 75 mm
Height to Laseraxis (h2): 60 mm
Height of Base (h3): 25 mm
Mount Diameter (d1): Ø 12 mm
Diameter of Base (d2): Ø 45 mm
Width of Mount (b): 26 mm
Height of Mount (g): 50 mm
Height of Mount Head (k): 50 mm
Depth of Mount (t): 15 mm
Angle of Rotation Alpha (α): 360 °
Angle of Rotation Beta (β): ± 90 °
